Airtac AirTAC 2KW Fluid Control Valve 2KW03006-X0
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW03006-X0 Fluid Control Valve Technical Details
- Model: 2KW03006-X0 (2KW Series)
- Type: 3-position, 5-way closed center solenoid valve
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 L/min (Cv=1.2) at 0.5 MPa
- Weight: 380g ±5% (including coil)
- Dimensions: 80mm(L) × 50mm(W) × 65mm(H)
- Seal materials: HNBR/Nitrile compound (standard), optional FKM for chemical resistance
- Temperature range: -10℃ to 80℃ (14°F to 176°F)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Response time: ≤30ms (energize), ≤20ms (de-energize)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with dual solenoid operation, featuring a unique pressure-balanced spool design for reduced actuation force. The anodized aluminum body with stainless steel internals ensures corrosion resistance in humid environments. Includes manual override and position indicator. Requires 5μm filtration (40μm for basic operation). Compatible with ISO 15407-1 standards.
- Automated assembly line clamping systems
- Beverage filling machine pressure regulation
- Plastic injection molding machine actuators
- Wastewater treatment plant pneumatic gates
- Semiconductor cleanroom equipment
- Hydraulic system pilot stage control
Installation guidelines:
Mount horizontally with coil upward. Allow 15mm clearance for heat dissipation.
Use Loctite 542 on port threads. Lubricate with ISO VG32 pneumatic oil if
operated below -5℃. Perform monthly exhaust port cleaning in high-particulate environments.
Critical note:
Not compatible with phosphate ester fluids. Maximum allowable
pressure spikes: 1.5x rated pressure for ≤100ms. Always install
downstream lockout valve for maintenance.
| Property | Property Value |
|---|---|
| sku | 2KW03006-X0 |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
