Airtac AirTAC 2KW Fluid Control Valve 2KW03008C
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW Series Fluid Control Valve 2KW03008C Technical Details
- Model: 2KW03008C
- Type: 3-position, 5-way pilot-operated (closed center)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 L/min (Cv=1.8)
- Response time: ≤35ms (energize), ≤50ms (de-energize)
- Weight: 300g ±5%
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H) (excluding fittings)
- Seal material: Fluororubber (FKM) standard (NBR available on request)
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Power consumption: ≤2.5W (DC), ≤3.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement 9mm)
- Hysteresis: ≤10% of rated voltage
High-flow proportional control valve with closed-center functionality, featuring brass body construction with anodized aluminum solenoid housing. Designed for precise mid-stroke positioning in pneumatic systems requiring intermediate states. Includes manual override and surge protection circuitry. Requires 5μm filtered air with ISO 8573-1:2010 Class 3 air quality.
- Automated assembly line clamping mechanisms
- Plastic injection molding machine actuators
- Textile machinery tension control systems
- Automotive brake testing equipment
- Food processing conveyor speed modulation
- Semiconductor wafer handling robots
Installation guidelines:
Maintain horizontal mounting position (±15° tolerance). Use flexible tubing for
vibration isolation in high-cycle applications. Perform monthly lubrication
of manual override mechanism in high-humidity environments.
Critical note:
Do not apply reverse polarity to DC models. Allow 2-minute cooldown between
continuous duty cycles exceeding 15 minutes at maximum pressure.
| Property | Property Value |
|---|---|
| sku | 2KW03008C |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC 110V |
