Airtac APB Straight Tee Fitting APB14-04
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
AirTAC APB Series Positive Tee Connector APB14-04 Technical Details
- Model: APB14-04 (Standard Straight Thread Type)
- Type: Equal-diameter pneumatic tee connector
- Thread Standard: PT1/8 (BSPP) female threads at all ports
- Material: Lead-free brass with nickel plating (CAC406)
- Surface Treatment: Electrostatic epoxy coating
- Pressure Rating: 0.05-1.0 MPa (7-145 psi)
- Burst Pressure: ≥3.0 MPa (435 psi)
- Temperature Range: -5℃ to 80℃ (23℉ to 176℉)
- Seal Material: HNBR rubber (high nitrile)
- Fluid Compatibility: Compressed air, inert gases (N₂ recommended)
- Weight: 18.5±0.3g
- Dimensions: 21.5mm (L) × 21.5mm (W) × 25.4mm (H)
- Port-to-Port Spacing: 14mm center distance between adjacent ports
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant, REACH SVHC-free
Precision-machined brass tee connector with triple-sealing design (thread seal + face seal + O-ring) for leak-free branching in pneumatic circuits. Features anti-vibration grooves and color-coded port indicators (blue base with white flow arrows). Compatible with 8-10mm tubing via push-in fittings when used with appropriate sleeves.
- Branching main air supply lines in automation workstations
- Pressure gauge manifold connections
- Pneumatic tool air distribution blocks
- Medical gas line splitters (oxygen/nitrogen systems)
- Robotic end-effector control circuits
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads. Tighten to 12-15N·m torque using a crowfoot wrench.
For vertical installations, orient flow arrow upward to prevent debris accumulation. Perform pressure test at 1.5× operating pressure after assembly.
| Property | Property Value |
|---|---|
| sku | APB14-04 |
