Airtac APB Straight Tee Fitting APB4-01
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
AirTAC APB Series Tee Connector APB4-01 Technical Specifications
- Model: APB4-01 (Straight Thread)
- Type: Precision machined tee fitting with metal-to-metal seal
- Thread standard: PT1/8 (BSPP) / NPT1/8 optional
- Material: Brass with nickel plating (Stainless steel SS304 variant available)
- Pressure rating: 0.05-1.5 MPa (7-217 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal type: Integrated O-ring (NBR standard, FKM optional)
- Surface hardness: ≥HV200 nickel layer
- Weight: 18g ±0.5g
- Dimensions: 20mm (L) × 20mm (W) × 20mm (H)
- Torque resistance: ≤25N·m installation torque
- Leakage rate: <0.1cc/min at 0.5MPa
High-flow tee connector with triple sealing structure (thread + end face + radial), featuring 360° rotatable ports for flexible piping arrangements. The precision-ground threads ensure leak-free connections in high-vibration environments. Compatible with air, inert gases, and water-based fluids.
- Pneumatic circuit branching in automated assembly lines
- Instrumentation air distribution systems
- Coolant line junctions in CNC machinery
- Vacuum system manifolds
- Robotic end-effector pneumatic networks
Installation protocol:
Apply PTFE tape clockwise on male threads (2.5 wraps recommended).
Hand-tighten first, then use a torque wrench for final 1/4 turn.
Avoid cross-threading - align ports before engagement.
Maximum re-use cycles: 5 times with seal inspection.
| Property | Property Value |
|---|---|
| sku | APB4-01 |
