Airtac APB Straight Tee Fitting APB4-M5
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APB4-M5
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple model specifications, widely applicable to various pneumatic systems;
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
Maintenance note:
Replace immediately if brass body shows visible deformation exceeding 0.1mm
or seal groove diameter exceeds 5.3mm. Compatible with ISO 8573-1:2010
[4:4:3] class compressed air.
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
AirTAC APB Series Positive Tee Connector APB4-M5 Technical Details
- Model: APB4-M5
- Type: Equal tee (straight-through flow path)
- Body material: Brass (CuZn39Pb3) with electroless nickel plating
- Seal material: NBR (Nitrile) rubber
- Thread specification: M5×0.8 (ISO 228-1 G-thread compatible)
- Port configuration: 3-way (1 inlet, 2 outlets)
- Max working pressure: 1.0 MPa (145 psi)
- Pressure range: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Flow coefficient (Cv): 0.15
- Weight: 9.2±0.3g
- Dimensions: 18mm(L) × 18mm(W) × 18mm(H)
- Surface roughness: Ra ≤1.6μm
- Vibration resistance: ≤10-55Hz, 1.5mm amplitude
Precision-machined brass tee connector featuring symmetrical flow channels for balanced pneumatic distribution. The self-aligning thread design prevents cross-threading during installation. Nickel plating provides corrosion resistance in humid environments (salt spray tested to 96hrs).
Installation Guidelines:
- Apply 2-3 drops of pneumatic sealant (viscosity ≤30 cSt) on threads
- Hand-tighten first, then torque to 0.8-1.2 N·m using crowfoot wrench
- Align flow arrow (cast mark) with primary airflow direction
- Install after F.R.L. units (Filter-Regulator-Lubricator)
- Branch line creation in compact pneumatic manifolds
- Sensor air supply splitting in robotic end effectors
- Vacuum system distribution in SMT equipment
- Medical device pneumatic circuit branching
- Laboratory automation gas line management
Maintenance note:
Replace immediately if brass body shows visible deformation exceeding 0.1mm
or seal groove diameter exceeds 5.3mm. Compatible with ISO 8573-1:2010
[4:4:3] class compressed air.
| Property | Property Value |
|---|---|
| sku | APB4-M5 |
