Airtac APC Threaded Quick Connect Coupling APC10-M10
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC Series Threaded Quick Connector APC10-M10 Technical Details
- Model: APC10-M10
- Type: Push-to-connect threaded fitting (straight)
- Thread specification: M10×1.0 male (ISO 228 G1/8 equivalent)
- Material: Brass (nickel-plated) with PPS housing
- Seal material: HNBR (Hydrogenated Nitrile)
- Operating temperature: -20℃ to +80℃
- Pressure range: 0.2-1.0 MPa (29-145 PSI)
- Tube compatibility: Ø10mm OD polyurethane/nylon tubing
- Flow coefficient (Cv): 1.8
- Leakage rate: <10 bubbles/min under 0.5 MPa pressure
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Weight: 48g ±2g
- Dimensions: 40mm(L) × 16mm(W) × 25mm(H)
- Surface treatment: Electroless nickel plating (5-8μm)
High-flow pneumatic connector featuring one-touch tube locking mechanism with visual release confirmation. The dual-oring design ensures leak-free performance in dynamic applications. Rotatable 340° collar allows flexible orientation adjustment post-installation. Meets ISO 14743 fatigue resistance standards (50,000+ cycles).
- Robotic arm pneumatic tool changers
- CNC machine coolant line connections
- Industrial vacuum system maintenance ports
- Food packaging machine air supply lines
- Semiconductor wafer handling equipment
Installation protocol:
Apply 2-3 drops of pneumatic oil to tube end before insertion.
Ensure full insertion until hearing audible "click".
Perform pull test (15N force) to verify engagement.
Do not use silicone-based lubricants with HNBR seals.
| Property | Property Value |
|---|---|
| sku | APC10-M10 |
| Insert Tube | <10mm> |
| Threaded Port | M10 |
