Airtac APC Threaded Quick Connect Coupling APC10-M12
$3.84
Regular price
$11.34
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APC10-M12
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation protocol:
Apply thread sealant only on male threads (not on first two threads).
Use 18-22N·m torque with calibrated wrench. Perform pull-out test
(≥70N force required) after assembly. Replace collet spring every
50,000 cycles in high-vibration environments.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC10-M12 Threaded Quick Connector Technical Details
- Model: APC10-M12
- Series: APC (Advanced Pneumatic Connection)
- Thread type: M12×1.0 external thread (ISO 228-1 standard)
- Compatible tube OD: Φ10mm (9.5-10.5mm tolerance range)
- Max working pressure: 1.5 MPa (15 bar)
- Burst pressure: ≥4.5 MPa
- Temperature range: -20℃ to +80℃ (continuous use)
- Body material: Nickel-plated brass (CW617N)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Insertion force: ≤50N (with lubrication)
- Vibration resistance: 10-2000Hz, 5G acceleration
- Weight: 38g ±2g
- Dimensions: 42mm(L) × 24mm(W) × 24mm(H)
- IP rating: IP67 (dust/water resistant)
- Certifications: RoHS compliant, REACH SVHC-free
High-cycle pneumatic connector featuring 360° rotatable sleeve design for flexible hose routing. Precision-machined threads with anti-vibration locking teeth ensure secure connections in dynamic environments. Integrated O-ring groove prevents seal extrusion under pressure spikes.
Typical Applications:
- Robotic arm pneumatic tool changers
- CNC machine coolant line connections
- Packaging equipment air knife systems
- Semiconductor wafer handling robots
- Electric vehicle battery cooling systems
Installation protocol:
Apply thread sealant only on male threads (not on first two threads).
Use 18-22N·m torque with calibrated wrench. Perform pull-out test
(≥70N force required) after assembly. Replace collet spring every
50,000 cycles in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | APC10-M12 |
| Insert Tube | <10mm> |
| Threaded Port | M12 |
