Airtac APC Threaded Quick Connect Coupling APC10-M14
$3.84
Regular price
$11.34
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APC10-M14
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation protocol:
Apply 12-15 N·m torque during threading. For plastic tubing,
pre-condition at 60℃ for 15 mins before first insertion in cold environments.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC10-M14 Threaded Quick Connector Technical Details
- Model: APC10-M14
- Type: Push-to-connect threaded fitting (straight)
- Thread Specification: M14×1.5 male thread (ISO 228-1)
- Applicable Tube OD: Φ10mm (flexible pneumatic tubing)
- Body Material: Nickel-plated brass (C3771)
- Seal Material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Pressure Range: 0.05-1.0 MPa (7-145 PSI)
- Temperature Range: -20℃ to 80℃ (continuous use)
- Peak Temperature Resistance: 120℃ (intermittent)
- Leakage Rate: ≤0.1 NL/min @ 0.5 MPa
- IP Rating: IP40 (non-submerged environments)
- Weight: 48g ±2g
- Dimensions: 40mm(L) × 14mm(Dia) × 14mm(Hex size)
- Certification: RoHS compliant, REACH SVHC-free
High-flow pneumatic connector with 45° tube insertion angle design for ergonomic assembly. Features triple sealing layers (thread, O-ring, tube grip) and anti-vibration collar. Brass construction ensures 50,000+ mating cycles with <3% pressure drop at max flow.
Installation Scenarios:
- Robotic arm pneumatic tool changers
- CNC machine coolant line quick-disconnect
- Food processing air knife systems
- Semiconductor fab equipment gas lines
- Electric vehicle battery cooling test benches
Installation protocol:
Apply 12-15 N·m torque during threading. For plastic tubing,
pre-condition at 60℃ for 15 mins before first insertion in cold environments.
Fluid Compatibility:
Compressed air (ISO 8573-1 Class 2), inert gases, and vacuum applications.
Not recommended for steam, acids, or phosphate ester fluids.
| Property | Property Value |
|---|---|
| sku | APC10-M14 |
| Insert Tube | <10mm> |
| Threaded Port | M14 |
