Airtac APC Threaded Quick Connect Coupling APC10-M16
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC Series Threaded Quick Connector APC10-M16 Technical Details
- Model: APC10-M16
- Thread Type: Metric fine thread (external)
- Thread Size: M16×1.5
- Material: Brass (nickel-plated) with PPS resin body
- Seal Material: HNBR (Hydrogenated Nitrile) O-ring
- Operating Pressure: 0.05-1.0 MPa
- Burst Pressure: ≥3.0 MPa
- Temperature Range: -20℃ to 80℃
- Tube Compatibility: Ø10mm OD polyurethane/nylon tubing
- Flow Rate: 350 NL/min (@0.5MPa)
- Leakage Rate: ≤20 cm³/min (under max pressure)
- Weight: 48g ±2g
- Dimensions: 42mm(L) × 24mm(W) × 32mm(H)
- IP Rating: IP40 (non-submerged applications)
- Certification: RoHS compliant
High-flow push-to-connect fitting with 360° rotatable union, designed for maintenance-free pneumatic systems. Features double-locking sleeve mechanism for secure tube retention and color-coded collar (standard blue) for quick identification. The nickel-plated brass construction resists corrosion in humid environments.
- Modular pneumatic assembly lines
- Robotic end-effector tooling connections
- CNC machine coolant line junctions
- Industrial vacuum system hookups
- Packaging machine air knife attachments
Installation protocol:
Insert tube until it bottoms out (audible click). For disconnection,
press the stainless steel release collar fully while withdrawing tubing.
Avoid side-load forces exceeding 15N on connected tubes.
| Property | Property Value |
|---|---|
| sku | APC10-M16 |
| Insert Tube | <10mm> |
| Threaded Port | M16 |
