Airtac APC Threaded Quick Connect Coupling APC12-M16X1.5
$4.36
Regular price
$11.86
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APC12-M16X1.5
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation guidelines:
(1) Cut tube ends square and deburr before insertion.
(2) Engage thread with 18-22 N·m torque using backup wrench.
(3) Confirm full tube insertion via inspection window.
(4) Perform pressure test at 110% max operating pressure.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC12-M16X1.5 Threaded Quick-Connect Coupling Specifications
- Model: APC12-M16X1.5
- Type: One-touch push-to-connect fitting with male metric thread
- Thread specification: M16×1.5 (external thread, 6g tolerance)
- Tube compatibility: 12mm OD polyurethane/nylon tubing
- Material: Nickel-plated brass body, PPS resin lever, NBR seals
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Proof pressure: 1.5 MPa (217 psi)
- Leakage rate: ≤0.1 Nml/min @ 0.5 MPa (helium test)
- Weight: 48g ±2g
- Dimensions: 46mm(L) × 22mm(W) × 22mm(H)
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
High-flow pneumatic coupling featuring a 45° angled release lever for tool-free tube insertion/removal. The precision-machined stainless steel collet provides secure grip on tubes while maintaining 360° rotatability. Sealing performance meets ISO 6150 B-series standards.
Typical Applications:
- Modular pneumatic circuit assembly lines
- CNC machine tool coolant systems
- Industrial robot end-effector connections
- Compressed air distribution in cleanrooms
- Packaging machine air knife installations
Installation guidelines:
(1) Cut tube ends square and deburr before insertion.
(2) Engage thread with 18-22 N·m torque using backup wrench.
(3) Confirm full tube insertion via inspection window.
(4) Perform pressure test at 110% max operating pressure.
| Property | Property Value |
|---|---|
| sku | APC12-M16X1.5 |
| Insert Tube | 12mm |
| Threaded Port | M16×1.5 |
