Airtac APC Threaded Quick Connect Coupling APC12-M20
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC Series Threaded Quick Connector APC12-M20 Technical Details
- Model: APC12-M20
- Thread standard: Metric (M20×1.5)
- Port configuration: M20 male thread to push-in fitting
- Tube compatibility: 12mm OD pneumatic tubing
- Material: Nickel-plated brass body
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE backup ring
- Pressure range: 0.2-1.0 MPa (29-145 PSI)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Max flow rate: 320 L/min (at 0.5 MPa)
- Leakage rate: ≤3 bubbles/min (ISO 6952 standard)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Weight: 118g ±2g
- Dimensions: 58mm(L) × 32mm(W) × 28mm(H)
- Surface treatment: Electroless nickel plating (8-12μm)
- Reconnect force: ≤70N (with tube retention clip)
Heavy-duty quick-disconnect coupling featuring triple-locking teeth mechanism for vibration resistance. The 45° angled release collar enables single-handed operation in confined spaces. Includes built-in O-ring groove protection to prevent extrusion under pressure spikes. Compatible with ISO 8434-1 air preparation systems.
- Robotic welding station pneumatic tooling
- CNC machine tool coolant line connections
- Plastic injection molding machine air circuits
- Food processing pneumatic actuator networks
- Semiconductor fab equipment gas lines
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (DO NOT over-tighten - max torque 35Nm).
Ensure tubing is cut square and deburred before insertion. Perform pressure tests at
1.25× operating pressure before commissioning.
| Property | Property Value |
|---|---|
| sku | APC12-M20 |
| Insert Tube | 12mm |
| Threaded Port | M20 |
