Airtac APC Threaded Quick Connect Coupling APC14-02
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC14-02 Threaded Quick Connector Technical Details
- Model: APC14-02
- Series: APC (Advanced Pneumatic Connection)
- Thread standard: G1/4 (ISO228-1 compliant)
- Tube OD compatibility: 8mm (5/16")
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥4.5 MPa
- Temperature range: -20℃ to 80℃
- Body material: Nickel-plated brass (C3771)
- Seal material: HNBR (Hydrogenated Nitrile)
- Thread engagement: 10±1 turns
- Leakage rate: <10 cm³/min @ 0.5 MPa
- Weight: 28±2g
- Dimensions: 38mm(L) × 21mm(W) × 21mm(H)
- Vibration resistance: 10-2000Hz, 10G acceleration
- Certifications: RoHS compliant, REACH tested
High-flow pneumatic coupling with 45° push-to-connect mechanism, featuring anti-vibration locking collar and dust-resistant sleeve. The precision-machined internal flow path achieves 95%+ flow efficiency compared to standard connectors. Includes built-in O-ring retention groove for secure sealing.
- Industrial automation pneumatic lines
- CNC machine tool air supply connections
- Packaging equipment quick-change tooling
- Laboratory instrument gas delivery systems
- Mobile hydraulic/pneumatic hybrid circuits
Maintenance protocol:
Lubricate O-rings with silicone grease (ISO 6743-4 FG grade) every
5,000 cycles. Use torque-limited wrench (8-10Nm) for thread assembly
to prevent over-tightening. Replace if insertion force exceeds 35N.
| Property | Property Value |
|---|---|
| sku | APC14-02 |
| Insert Tube | 14mm |
| Threaded Port | PT1/4 |
