Airtac APC Threaded Quick Connect Coupling APC14-03
$6.94
Regular price
$14.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APC14-03
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation tip:
For optimal performance, insert tube perpendicularly until hearing a "click".
Perform monthly checks for dust accumulation in the collet mechanism.
Not recommended for hydraulic fluids or aggressive chemicals.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC14-03 Threaded Quick Connector Specifications
- Model: APC14-03
- Thread type: M5 × 0.8 male thread (metric)
- Tube OD compatibility: 4mm (1/8") pneumatic tubing
- Material: PBT + Glass Fiber (body), NBR seals
- Operating pressure: 0.2-1.0 MPa (29-145 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Flow rate: 250 L/min (ANR) at 0.5 MPa
- Weight: 12g ±0.5g
- Dimensions: 28mm(L) × 18mm(W) × 16mm(H)
- Installation hole: 5mm diameter
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant
Push-to-connect fitting with precision-machined brass thread insert for secure sealing. Features 360° rotatable collar for easy tube alignment and color-coded identification (standard blue body). Includes built-in tube retention clip preventing accidental disconnection.
Ideal Applications:
- Modular pneumatic control panels
- Robotic arm tool changers
- CNC machine air blast systems
- Laboratory analytical instruments
- Semiconductor wafer handling equipment
Installation tip:
For optimal performance, insert tube perpendicularly until hearing a "click".
Perform monthly checks for dust accumulation in the collet mechanism.
Not recommended for hydraulic fluids or aggressive chemicals.
| Property | Property Value |
|---|---|
| sku | APC14-03 |
| Insert Tube | 14mm |
| Threaded Port | PT3/8 |
