Airtac APC Threaded Quick Connect Coupling APC14-04
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC14-04 Threaded Quick Connector Technical Details
- Model: APC14-04 (APC Series)
- Thread type: Male thread G1/4 (BSPP)
- Tube OD compatibility: 4mm (metric) / 5/32" (imperial)
- Material: Brass body with nickel plating
- Seal material: NBR (Nitrile) rubber
- Max working pressure: 1.0 MPa (145 psi)
- Pressure range: 0.2-1.0 MPa (29-145 psi)
- Temperature range: -5℃ to 60℃ (23℉ to 140℉)
- Leakage rate: ≤3 bubbles/min (ISO 6952 standard)
- Weight: 48g ±2g
- Dimensions: 30mm(L) × 16mm(W) × 30mm(H)
- Thread engagement depth: 8mm minimum
- Vibration resistance: ≤10Hz @ 1.5mm amplitude
High-flow pneumatic coupling with push-to-connect functionality, featuring a 30° swivel capability post-installation for flexible tubing routing. The chrome-plated brass construction ensures corrosion resistance in humid environments. Integrated O-ring provides dual sealing: static seal at threads and dynamic seal at tube interface.
- Pneumatic cylinder manifold connections
- CNC machine tool air supply lines
- Plastic injection molding machine air circuits
- Semiconductor manufacturing equipment
- Automated packaging line actuators
Installation protocol:
Hand-tighten until snug, then apply 1/4 additional turn with wrench.
Always use two wrenches - counter-hold the base fitting during assembly
to prevent torque transfer to downstream components.
| Property | Property Value |
|---|---|
| sku | APC14-04 |
| Insert Tube | 16mm |
| Threaded Port | PT 1/2 |
