Airtac APC Threaded Quick Connect Coupling APC16-01
$7.97
Regular price
$15.47
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APC16-01
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation note:
Cut tubing ends square and deburr before insertion. For maximum seal integrity,
insert tubes until they click and then pull back slightly to engage locking mechanism.
Not recommended for continuous rotation applications exceeding 30 RPM.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC16-01 Threaded Quick Connector Specifications
- Model: APC16-01
- Type: Push-to-connect threaded fitting (straight)
- Thread standard: M5×0.8 male thread (ISO 228-1)
- Tube compatibility: Ø4mm (5/32") OD pneumatic tubing
- Max working pressure: 1.0 MPa (145 psi)
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃
- Body material: Nickel-plated brass (CuZn39Pb3)
- Seal material: NBR (Nitrile) rubber
- IP rating: IP40 (non-submerged applications)
- Weight: 24g ±1g
- Dimensions: 28mm(L) × 16mm(W) × 16mm(H)
- Thread engagement depth: 6mm
- Flow coefficient (Cv): 0.12
Precision quick-connect pneumatic fitting with tool-free tube insertion. Features a 360° rotatable collar for easy alignment and maintenance. The double-locking sleeve design prevents accidental disconnection under vibration. Compatible with air, inert gases, and vacuum systems.
Typical Applications:
- Robotic arm pneumatic circuits
- CNC machine tool air supply lines
- Semiconductor manufacturing equipment
- Food-grade compressed air systems (when using oil-free air)
- Laboratory instrumentation gas connections
Installation note:
Cut tubing ends square and deburr before insertion. For maximum seal integrity,
insert tubes until they click and then pull back slightly to engage locking mechanism.
Not recommended for continuous rotation applications exceeding 30 RPM.
Maintenance:
- Inspect O-ring every 6 months (12 months for N2 systems)
- Lubricate threads with PTFE tape or silicone paste
- Max reconnection cycles: 500 times (with original tube)
| Property | Property Value |
|---|---|
| sku | APC16-01 |
| Insert Tube | 16mm |
| Threaded Port | PT1/8 |
