Airtac APC Threaded Quick Connect Coupling APC8-02G
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APC8-02G
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation protocol:
Hand-tighten thread until snug, then apply 1/4 turn with wrench.
Ensure tubing is cut square and fully inserted until the 8mm depth mark.
Maximum reconnection cycles: 50 times while maintaining seal integrity.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC8-02G Threaded Quick Connector Specifications
- Model: APC8-02G
- Type: Push-to-connect threaded fitting (male thread)
- Body material: Nickel-plated brass (C3604)
- Seal material: FKM (Fluoroelastomer)
- Thread standard: G1/8 (ISO 228-1)
- Tube compatibility: Ø8mm OD pneumatic tubing
- Operating pressure: 0.05–1.0 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 150℃ (with FKM seals)
- Thread torque resistance: 8-10 N·m
- Weight: 28.5±0.5g
- Dimensions: 32mm(L) × 18mm(W) × 18mm(H)
- Vibration resistance: 10-2000Hz, 10G acceleration
- Certification: RoHS compliant
High-flow quick-disconnect fitting with 30° cone sealing structure, featuring 5-click audible engagement confirmation. Anti-vibration design maintains connection integrity under mechanical stress. Compatible with air, inert gases, and vacuum systems.
Typical Applications:
- Robotic arm pneumatic tool changers
- CNC machine coolant line connections
- Semiconductor wafer handling vacuum systems
- High-cycle packaging machine air circuits
- Laboratory gas chromatography setups
Installation protocol:
Hand-tighten thread until snug, then apply 1/4 turn with wrench.
Ensure tubing is cut square and fully inserted until the 8mm depth mark.
Maximum reconnection cycles: 50 times while maintaining seal integrity.
| Property | Property Value |
|---|---|
| sku | APC8-02G |
| Insert Tube | <8mm> |
| Threaded Port | G1/4" Thread |
