Airtac APC Threaded Quick Connect Coupling APC8-M16
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APC8-M16
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Compact design enables space-saving installation with cost-effective performance. Features M5 metric thread integrated with O-ring and pre-applied sealant on threaded portion, ensuring leak-proof threaded connections.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
Installation Guide:
Hand-tighten until 1.5-2 threads remain visible. For maintenance,
depress lock lever fully before tube removal. Lubricate threads
with PTFE paste (not included) for high-vibration environments.
Avoid using with petroleum-based lubricants. Maximum tightening torque:
18N·m. Always perform pressure test below 0.3MPa after installation.
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC Series Threaded Quick Connect Fitting APC8-M16 Technical Details
- Full Model Number: APC8-M16
- Thread Type: Metric coarse thread (external)
- Thread Size: M16×1.5
- Material: Nickel-plated brass body / PPS resin lever
- Operating Pressure: 0.05-1.0 MPa (7-145 psi)
- Temperature Range: -5℃ to 80℃ (23℉ to 176℉)
- Tube Compatibility: Ø8mm polyurethane/nylon tubing
- Seal Material: HNBR (Hydrogenated Nitrile) O-rings
- Weight: 82g ±2g
- Dimensions: 48mm(L) × 28mm(W) × 36mm(H)
- Vibration Resistance: ≤10Hz @ 2mm amplitude
- Leakage Rate: <3 bubbles/min (ISO 6952 standard)
- Certification: RoHS compliant
High-flow pneumatic connector featuring push-to-connect installation with 360° rotatable fitting. The chrome-plated brass construction ensures corrosion resistance in humid environments. Integrated safety lock lever prevents accidental disconnection during operation.
Common Applications:
- Pneumatic cylinder port connections
- Air compressor tool quick-change systems
- Industrial robot end effector air supply
- Beverage dispensing machine tubing networks
- CNC machine coolant line attachments
Installation Guide:
Hand-tighten until 1.5-2 threads remain visible. For maintenance,
depress lock lever fully before tube removal. Lubricate threads
with PTFE paste (not included) for high-vibration environments.
Avoid using with petroleum-based lubricants. Maximum tightening torque:
18N·m. Always perform pressure test below 0.3MPa after installation.
| Property | Property Value |
|---|---|
| sku | APC8-M16 |
| Insert Tube | <8mm> |
| Threaded Port | M16 |
