Airtac APC Threaded Quick Connect Coupling APC8-M8
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC Series Threaded Quick Connector APC8-M8 Technical Details
- Model: APC8-M8
- Type: Push-to-connect threaded fitting with 360° rotatable sleeve
- Body material: Nickel-plated brass (CuZn39Pb3)
- Thread specification: M8×1.0 male thread (ISO 1179-2 standard)
- Tube compatibility: Ø8mm OD pneumatic tubing (PU/Nylon 11/PE)
- Pressure range: 0.2-1.0 MPa (29-145 PSI)
- Temperature range: -20℃ to +80℃ (-4°F to +176°F)
- Seal material: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Leakage rate: <10 cm³/min at 0.5 MPa pressure
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- IP rating: IP40 (protected against 1mm+ solids)
- Weight: 52g ±2g
- Dimensions: 42mm(L) × 24mm(W) × 24mm(H)
High-flow pneumatic connector featuring automatic tube retention system with visible release collar. The 8mm bore design ensures minimal pressure drop (ΔP <0.02 MPa at 5L/min flow rate). Precision-machined threads include anti-vibration flank geometry for secure mounting in dynamic applications.
- Industrial automation: Robotic end effectors, CNC tool changers
- Packaging lines: Compressed air distribution in filling machines
- Semiconductor manufacturing: Cleanroom-compatible dust-resistant design
- Food processing: Corrosion-resistant for humid environments
Maintenance tip:
For optimal performance, insert tubes perpendicularly until "click" engagement.
Rotate sleeve 15° counterclockwise for tube release. Lubricate threads with PTFE paste
(not tape) when installing in aluminum manifolds to prevent galling.
| Property | Property Value |
|---|---|
| sku | APC8-M8 |
| Insert Tube | <8mm> |
| Threaded Port | M8 |
