Airtac APCF Female Thread Straight Connector APCF10-M16
2. Features excellent flow performance with capacity equivalent to tubing inner diameter;
3. Enables tool-free push-in/pull-out operation while maintaining secure and durable tubing connections;
4. Pre-applied thread sealant with M5 metric threads and integrated sealing washers ensure leak-proof threaded joints;
5. Nickel-plated brass body provides superior corrosion and contamination resistance for expanded application scope.
Category: Internal Thread Straight Fittings | Brand: AirTAC | Series: APCF
AirTAC APCF Female Thread Straight Fitting APCF10-M16 Technical Details
- Model: APCF10-M16
- Type: Female threaded straight connector (equal diameter)
- Thread Standard: Metric fine thread (M16×1.5)
- Material: Anodized aluminum alloy (A6063-T5)
- Seal Material: HNBR rubber (hydrogenated nitrile)
- Pressure Range: 0.05-1.0 MPa (7-145 PSI)
- Temperature Range: -20℃ to 80℃ (continuous operation)
- Burst Pressure: ≥3.0 MPa (435 PSI)
- Surface Treatment: Clear anodized (8-12μm thickness)
- Weight: 28±2g (without packaging)
- Dimensions: 40mm(L) × 16mm(OD) × 16mm(ID)
- Thread Engagement: 13mm minimum insertion depth
- Flow Rate: 350 NL/min (at 0.5MPa pressure drop)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant, ISO 14001 manufacturing
High-flow straight connector with precision-machined M16×1.5 female threads on both ends, featuring anti-vibration grooves and triple-sealing design (metal-to-metal seat + dual O-rings). The 45° chamfered entry ensures smooth tube insertion. Ideal for medium-pressure pneumatic lines requiring frequent disassembly.
- Connecting pneumatic cylinders in robotic welding arms
- Modular assembly stations with quick-change tooling
- Laser cutting machine air supply lines
- Food processing equipment (HNBR seals compatible with food-grade lubricants)
- Semiconductor manufacturing vacuum/pressure lines
Installation protocol:
Apply thread sealant (LOCTITE 577 recommended) on male threads only.
Tighten to 25-30 N·m torque using crowfoot wrench.
Replace O-rings every 5,000 connection cycles or 2 years (whichever comes first).
