Airtac APD T-Side Port Tee Fitting APD4-M12
$3.84
Regular price
$11.34
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APD4-M12
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to diverse pneumatic systems;
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
Installation protocol:
Apply thread sealant (Loctite 577 recommended) to male threads before assembly.
Tighten in 1/4 turn increments until snug. Avoid cross-threading - initial alignment
must maintain 90° angle between connector and mating part. Perform pressure test
at 1.25× operating pressure after installation.
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Type Tee Connector APD4-M12 Technical Details
- Model: APD4-M12
- Type: T-shaped pneumatic tee connector (equal diameter)
- Thread specification: M12×1.5 (ISO 1179-2 compliant)
- Material: Nickel-plated brass (stainless steel variant available as APD4-M12-SS)
- Pressure rating: 0.5-1.5 MPa (7-217 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal type: Embedded O-ring (NBR material)
- Surface treatment: Electroless nickel plating (≥12μm thickness)
- Flow coefficient (Cv): 0.22
- Weight: 12.5g ±0.3g
- Dimensions: 40mm(L) × 12mm(D) × 12mm(Branch D)
- Port configuration: Three M12 female threads (1 inlet, 2 outlets)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant, REACH SVHC-free
Precision-machined tee connector with triple-port flow distribution, featuring anti-vibration thread design and leak-proof NBR seals. The hexagonal body allows tool-assisted tightening (14mm wrench size). Compatible with ISO 15407-1 standard tubing. Maximum recommended torque: 18N·m.
Common Applications:
- Branching pneumatic circuits in robotic end effectors
- Modular pneumatic system prototyping
- Compressed air distribution in CNC machinery
- Sensor air supply splitting in automation lines
- Vacuum system manifold connections
Installation protocol:
Apply thread sealant (Loctite 577 recommended) to male threads before assembly.
Tighten in 1/4 turn increments until snug. Avoid cross-threading - initial alignment
must maintain 90° angle between connector and mating part. Perform pressure test
at 1.25× operating pressure after installation.
Service life:
500,000 cycles under standard conditions (23℃, 0.7MPa). Replace O-rings every
2 years or if leakage exceeds 0.5 bubbles/min during soap solution test.
