Airtac APH Hex Head Connector APH10-04
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH Hex Nipple Connector APH10-04 Technical Details
- Model: APH10-04 (Straight Thread Type)
- Thread Standard: Metric M10×1.25 male thread (ISO 1179-1)
- Material: Lead-free brass CW617N (RoHS compliant)
- Seal Type: Integrated O-ring (NBR 70±5 Shore A)
- Max Pressure: 1.5 MPa (15 bar / 217.5 psi)
- Temperature Range: -20℃ to 80℃ (continuous) / 120℃ peak (≤1hr)
- Surface Treatment: Electroplated zinc-nickel alloy (8-12μm) with yellow chromate
- Hex Size: 17mm wrench flat
- Weight: 28g ±1g
- Dimensions: 38mm(Total L) × 17mm(W) × 17mm(H)
- Thread Engagement: 10mm minimum recommended
- Certification: ISO 8434-1/DIN 3859-2
High-pressure resistant connector with precision-machined threads and corrosion-resistant plating. Features dual sealing structure: metal-to-metal thread contact for primary sealing and compressible O-ring for secondary leak prevention. Designed for vibration-prone environments with anti-loosening thread geometry.
- Pneumatic cylinder port connections
- Modular valve manifold assemblies
- Compressed air distribution systems
- CNC machine tool pneumatic circuits
- Food processing equipment (FDA-compliant grease option available)
Installation guidance:
Apply thread sealant (LOCTITE 577 recommended) to male threads only.
Tighten to 15-20 N·m torque using calibrated wrench. Avoid overtightening
which may deform O-ring groove. Inspect seal every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | APH10-04 |
