Airtac APH Hex Head Connector APH8-01
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH8-01 Hexagon Connector Technical Specifications
- Model: APH8-01
- Thread type: BSPP (G1/8) female threads both ends
- Material: Brass (CuZn39Pb3) with nickel plating
- Hex size: 10mm wrench flat
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥6 MPa
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal material: NBR (Nitrile) O-ring
- Surface roughness: Ra ≤1.6μm
- Weight: 15g ±0.5g
- Dimensions: 20mm(L) × 10mm(W) × 12mm(H)
- Compliance: ISO 1179-1 standard
- Corrosion resistance: 96hrs neutral salt spray test
Precision-machined pneumatic connector featuring dual-sealing structure with embedded O-ring and metal-to-metal contact. The hexagonal body design provides 360° tool access for secure installation in confined spaces. Nickel plating enhances corrosion resistance against moisture and hydraulic fluids.
- Pneumatic valve manifold block connections
- CNC machine tool air supply lines
- Industrial robot end-effector piping
- Compressed air instrumentation systems
- Food processing equipment (FDA-compliant grease option available)
Installation protocol:
Apply 2-3 drops of pneumatic sealant (Loctite 577 recommended) on threads.
Tighten with torque wrench at 12-15 N·m. Perform pressure test at 1.25×
working pressure after installation. Replace O-ring every 5,000 operating
hours or 2 years (whichever comes first).
| Property | Property Value |
|---|---|
| sku | APH8-01 |
