Airtac APH Hex Head Connector APH8-04
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH Series Hexagon Connector APH8-04 Technical Details
- Model: APH8-04 (Hexagon Straight Threaded Connector)
- Thread standard: PT1/8 (BSPP) female thread
- Tube OD compatibility: Ø8mm pneumatic tubing
- Material: Nickel-plated brass body
- Seal type: NBR O-ring with anti-vibration design
- Pressure rating: 0.05-1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Hex size: 12mm wrench flat
- Surface treatment: Electroplated zinc alloy (salt spray test 96hrs)
- Weight: 23g ±0.5g
- Dimensions: 25mm(L) × 12mm(W hex flats) × 18mm(H total height)
- Thread engagement depth: 7.5mm
- Flow coefficient (Cv): 0.45
High-pressure resistant pneumatic connector with precision-machined threads and dual-stage sealing. Features vibration-resistant structure with 30° swivel capability for hose alignment. Compatible with ISO 8434-1 standards, includes built-in tube stopper for secure push-to-connect installation.
- Pneumatic cylinder manifold assemblies
- CNC machine tool air supply circuits
- Plastic injection molding machine air lines
- Semiconductor manufacturing equipment
- Railway braking system connections
Installation protocol:
Apply thread sealant (PTFE tape optional) on male threads. Tighten with 12mm wrench using 8-10Nm torque.
Maximum 120° rotation after initial contact. Perform pressure test at 1.5x working pressure.
| Property | Property Value |
|---|---|
| sku | APH8-04 |
