Airtac APL L-type Elbow Fitting APL12-01
$4.36
Regular price
$11.86
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APL12-01
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to various pneumatic systems;
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 12-15 N·m torque.
Avoid cross-threading - hand-tighten 2 full rotations before final torque.
Not recommended for continuous rotation applications.
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Type Elbow Fitting APL12-01 Technical Details
- Model: APL12-01 (L-Type 90° Elbow)
- Material: Brass with nickel-plated surface
- Thread Standard: PT1/8 (BSPP) / Optional NPT1/8
- Through Hole Diameter: 12mm
- Max Working Pressure: 1.5 MPa (217 PSI)
- Temperature Range: -5℃ to 80℃
- Weight: 28g ±0.5g
- Dimensions: 32mm(Length) × 24mm(Width) × 24mm(Height)
- Seal Material: NBR (Nitrile Rubber)
- Surface Roughness: Ra ≤1.6μm
- Vibration Resistance: ≤10Hz @ 1.5mm amplitude
- Certification: RoHS compliant
Precision-machined L-shaped pneumatic connector featuring leak-proof design with dual O-ring seals. The 90° angled configuration enables space-saving plumbing in complex pneumatic circuits. Nickel plating provides corrosion resistance against moisture and mild chemicals.
Typical Applications:
- Robotic arm pneumatic tooling connections
- Packaging machine air line routing
- Medical device gas delivery systems
- CNC machine tool air cylinder networks
- Food processing equipment (dry air systems)
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 12-15 N·m torque.
Avoid cross-threading - hand-tighten 2 full rotations before final torque.
Not recommended for continuous rotation applications.
Compatible Accessories:
- AirTAC PIS12-01M push-in sleeves
- APU12 series plastic dust caps
- Works with Ø12mm OD polyurethane/nylon tubing
| Property | Property Value |
|---|---|
| sku | APL12-01 |
