Airtac APL L-type Elbow Fitting APL14-04
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Type Elbow Fitting APL14-04 Technical Details
- Model: APL14-04 (L-Type 90° Elbow)
- Thread standard: G1/4 (BSPP parallel thread)
- Material: Lead-free brass CW617N (nickel-plated surface)
- Seal type: EPDM O-ring (standard) / Optional NBR
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 3.0 MPa
- Burst pressure: 6.0 MPa
- Temperature range: -5℃ to 80℃ (EPDM) / 0℃ to 60℃ (NBR)
- Flow coefficient (Cv): 0.43
- Weight: 22g ±1g
- Dimensions: 28mm (L) × 18mm (W) × 28mm (H)
- Surface roughness: Ra ≤1.6μm (internal passages)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined L-shaped pneumatic connector with leak-proof design, featuring dual-plane sealing technology for zero-burr fluid paths. The 90° configuration optimizes compact installations while maintaining laminar airflow (turbulence reduction ≤8% at 0.7MPa). Compatible with ISO 1179-1 standards.
- Pneumatic cylinder port redirection in robotic arms
- Space-constrained manifold block connections
- Air preparation unit (FRL) outlet configurations
- Vacuum system plumbing with directional constraints
- Medical device pneumatic circuit bending applications
Mounting guidance:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten -
recommended torque 12-15N·m). For vertical downward installations,
use thread locker on female port to prevent vibration loosening.
- Optimal for Φ6mm (1/4") OD polyurethane/nylon tubing
- Max tube insertion depth: 15mm (with 2-stage grip teeth)
- Push-to-connect mechanism withstands 25N axial pull force
| Property | Property Value |
|---|---|
| sku | APL14-04 |
