Airtac APLF L-Shaped Female Thread Elbow APLF10-04
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF10-04 Technical Specifications
- Model: APLF10-04
- Type: 90° L-shaped female threaded elbow
- Thread standard: PT1/8 (BSPP) internal threads both ends
- Material: Brass (CuZn39Pb3) with nickel-plated surface
- Pressure rating: 0.1-1.0 MPa
- Temperature range: -20℃ to 80℃
- Weight: 18.5g ±0.5g
- Dimensions: 25mm (L1) × 25mm (L2) × 10mm (W)
- Thread engagement depth: 7mm per port
- Surface roughness: Ra ≤1.6μm
- Torque resistance: 1.5-2 Nm installation torque recommended
- Compatibility: Works with Ø4mm tubing (metric system)
Precision-machined L-shaped pneumatic connector designed for 90° directional changes in compact pneumatic systems. Features leak-proof tapered threads (BSPP) with dual O-ring grooves for positive sealing. Nickel plating enhances corrosion resistance in humid environments. Rated for 100,000+ duty cycles.
- Pneumatic valve manifold redirection
- Robotic arm tooling air supply lines
- CNC machine tool clamp circuits
- Medical device pneumatic connections
- Packaging machine actuator networks
Installation guidelines:
Apply PTFE tape or liquid sealant on male threads only. Tighten using 13mm open-end wrench on hex flats.
Avoid overtightening - stop when resistance increases sharply (1/4 turn past finger-tight). Perform pressure
test at 1.5x operating pressure after installation.
