Airtac APLF L-Shaped Female Thread Elbow APLF12-04
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF12-04 Technical Details
- Model: APLF12-04
- Type: L-shaped 90° pneumatic connector
- Thread standard: Rc (PT) / G (PF) options
- Female thread size: Rc1/8 (G1/8 equivalent available)
- Material: Lead-free brass with nickel plating
- Surface hardness: ≥HV300
- Pressure rating: 0.05–1.5 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -5℃ to 80℃ (non-freezing)
- Weight: 28±2g
- Dimensions: 32mm(L) × 24mm(W) × 24mm(H)
- Thread engagement depth: 8.5mm
- Flow coefficient (Cv): 0.15
- Compliance: RoHS 2.0 compliant
Precision-machined L-shaped pneumatic fitting designed for compact piping layouts. Features corrosion-resistant nickel plating and dual-thread standard compatibility. The 8.5mm deep threads ensure secure connections in high-vibration environments. Internal flow path optimized for minimal pressure drop.
- Pneumatic cylinder port redirection
- Tool-free maintenance access points
- Modular automation equipment manifolds
- Robotic arm end effector connections
- Packaging machine air circuit distribution
Installation guidance:
Apply 2-3 wraps of PTFE tape on male threads (do NOT use liquid sealant).
Tighten to 12-15 N·m torque maximum. Align elbow orientation before final tightening.
Avoid using with:• Aggressive chemicals (pH <4 or >11)
• Pulsed pressures above 2.5 MPa
• Thermal cycling applications
| Property | Property Value |
|---|---|
| sku | APLF12-04 |
