Airtac APLF L-Shaped Female Thread Elbow APLF12-M16
$4.87
Regular price
$12.37
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APLF12-M16
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Hexagonal edges with a turned outer circumference for space-saving installation;
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 14-16 N·m torque using crowfoot wrench.
Avoid overtightening - maximum 1/2 turn past finger-tight. For vertical installations, orient hex flats horizontally for service accessibility.
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF12-M16 Technical Details
- Full Model: APLF12-M16
- Type: 90° L-shaped pneumatic fitting with dual female threads
- Thread Specification: M16×1.5 (Metric fine thread)
- Material: Brass with nickel plating (CuZn39Pb3)
- Surface Hardness: ≥HV200
- Pressure Rating: 0.3-1.5 MPa (43.5-217.5 PSI)
- Temperature Range: -20℃ to 100℃ (continuous use)
- Proof Pressure: 2.25 MPa
- Burst Pressure: ≥3 MPa
- Weight: 52g ±2g
- Dimensions:
- Total Length (A): 32mm
- Thread Engagement Depth (B): 13mm
- Hex Size: 19mm across flats
- Center-to-End: 24mm
- Surface Roughness: Ra ≤3.2μm
- Compliance: RoHS 2.0 compliant
Precision-machined L-shaped connector designed for high-density pneumatic systems requiring directional flow changes. Features corrosion-resistant nickel plating and reinforced thread roots for 10,000+ mating cycles. The 19mm hex design allows tool engagement in confined spaces.
Industrial Applications:
- Pneumatic valve manifold interconnections
- Robotic arm tooling air supply lines
- CNC machine lubrication system plumbing
- Compressed air distribution in packaging lines
- Vacuum system plumbing for material handling
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 14-16 N·m torque using crowfoot wrench.
Avoid overtightening - maximum 1/2 turn past finger-tight. For vertical installations, orient hex flats horizontally for service accessibility.
| Property | Property Value |
|---|---|
| sku | APLF12-M16 |
