Airtac APLF L-Shaped Female Thread Elbow APLF16-04
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF16-04 Technical Details
- Model: APLF16-04
- Type: 90° L-shaped pneumatic fitting with female threads
- Thread Standard: BSPP (Parallel)
- Male Thread Size: G1/8 (R1/8 optional)
- Female Thread Size: G1/8
- Material: Brass with nickel plating (C3604 equivalent)
- Pressure Range: 0.3-1.5 MPa (4-217 PSI)
- Temperature Range: -5°C to 80°C
- Surface Roughness: Ra ≤1.6μm (thread contact areas)
- Seal Material: NBR (Nitrile) rubber
- Weight: 35g ±2g
- Dimensions: 28mm(L) × 28mm(W) × 25mm(H)
- Torque Limit: 1.2-1.5 N·m (during installation)
- Flow Coefficient: Cv ≈0.07
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered L-shaped connector featuring dual female threads for secure right-angle piping connections. The electroless nickel plating provides corrosion resistance exceeding 96hrs in salt spray tests. Designed with a reinforced root structure to prevent thread stripping during repeated installations.
- Compact pneumatic circuit layouts in robotic arms
- Direction-changing nodes in automated assembly lines
- Sensor mounting brackets requiring angled air supply
- Medical device pneumatic systems requiring hygienic connections
- Modular pneumatic training equipment
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads. Hand-tighten plus 1/4 turn with wrench.
Avoid aligning torque parallel to elbow axis to prevent material stress.
Pressure test at 1.25× system pressure after installation.
| Property | Property Value |
|---|---|
| sku | APLF16-04 |
