Airtac APLL Extended L Elbow APLL12-M16
2、Superior flow capacity with equivalent passage to tubing inner diameter for unrestricted flow;
3、Quick-connect design features tool-free tubing insertion/extraction with secure, durable connections;
4、Pre-applied thread sealant and M5 metric threads with integrated sealing washer ensure leak-proof thread connections;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention for extended application versatility.
Category: Extended L-Type Elbow Fittings , Brand: AirTAC , Series: APLL
AirTAC APLL Extended L-Shaped Elbow APLL12-M16 Technical Details
- Model: APLL12-M16
- Type: Extended L-shaped pneumatic fitting (90° elbow)
- Thread specification: M16×1.5 (internal thread both ends)
- Material: Brass with nickel plating (stainless steel optional)
- Operating pressure: 0.2-0.8 MPa (29-116 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) standard, FKM (Viton) optional
- Surface roughness: Ra ≤1.6μm
- Proof pressure: 1.5 MPa (217 PSI)
- Weight: 52g ±2g (brass version)
- Dimensions: 32mm(L) × 24mm(W) × 28mm(H)
- Installation torque: 3-5 Nm (brass), 5-7 Nm (stainless steel)
- Flow coefficient (Cv): 0.45
Extended-length L-shaped connector designed for confined pneumatic systems requiring directional flow changes. Features reinforced wall thickness (1.8mm minimum) and anti-vibration grooves. The extended neck (12mm beyond standard models) enables easier tool access during maintenance. Compatible with ISO 1179-1 standards.
- Robotic arm pneumatic circuit routing
- CNC machine tool air supply connections
- Plastic injection molding machine manifolds
- Compressed air distribution in automotive assembly lines
- Vacuum system plumbing for electronic component handling
Installation guidelines:
Apply thread sealant (LOCTITE 577 recommended) to male threads only.
Tighten using opposing wrench flats (19mm span). Maximum 1/2 turn past finger-tight.
Pressure test at 1.1× system pressure after installation.
