Airtac APX Y-Type Tee Fitting APX4-01
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Fitting APX4-01 Technical Details
- Model: APX4-01
- Type: Y-shaped 3-way connector (equal distribution)
- Material: Brass with nickel plating (stainless steel optional)
- Port configuration: 1/8" BSPP female threads (G1/8)
- Operating pressure: 0.05-1.0 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃
- Flow coefficient (Cv): 0.6
- Weight: 28g ±1g
- Dimensions: 25mm(L) × 25mm(W) × 25mm(H)
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered Y-branch pneumatic connector featuring symmetrical flow channels for balanced pressure distribution. The 60° angled design minimizes turbulent flow while maintaining compact dimensions. Corrosion-resistant nickel plating ensures durability in humid environments. Compatible with air, inert gases, and vacuum systems (1kPa abs).
- Pneumatic circuit branching in automation equipment
- Air supply distribution for multi-axis robotic systems
- Vacuum line splitting in pick-and-place machines
- Cooling system manifolds for laser cutting devices
- Modular pneumatic teaching platforms
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten beyond 1.5Nm torque).
For vertical mounting, position Y-axis horizontally to prevent particle accumulation.
Compatible with Ø4mm polyurethane tubing (max insertion force 50N).
| Property | Property Value |
|---|---|
| sku | APX4-01 |
