Airtac APX Y-Type Tee Fitting APX4-M5
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Series Y-Type Tee Connector APX4-M5 Technical Details
- Model: APX4-M5 (Y-Type)
- Body material: Nickel-plated brass (CuZn39Pb3)
- Thread specification: M5×0.8 (ISO 228-1 G-thread compatible)
- Port configuration: 3-way equal diameter (T-shaped flow path)
- Max working pressure: 1.5 MPa (217 psi)
- Pressure range: 0.05-1.5 MPa
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) with PTFE backup ring
- Surface treatment: Electroless nickel plating (5-8μm thickness)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Weight: 8g ±0.5g
- Dimensions: 20mm(L) × 12mm(W) × 12mm(H) (per branch)
- Port-to-port center distance: 16mm (vertical), 14mm (horizontal)
- Fluid compatibility: Air, inert gases, non-lubricated media
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Precision-engineered Y-shaped pneumatic connector featuring triple-ported flow distribution with uniform pressure maintenance. The compact nickel-plated brass construction provides excellent corrosion resistance and structural integrity in humid environments. Optimized internal channels minimize pressure drop (ΔP ≤0.02MPa @1MPa input).
- Modular pneumatic circuit branching in automation equipment
- Tooling fixture air supply distribution systems
- Medical device gas line splitting (oxygen/nitrogen mixers)
- Laboratory instrumentation pneumatic networks
- Packaging machine air knife synchronization
- Robotic end-effector multi-circuit control
Installation protocol:
Apply 2-3 wraps of PTFE tape (0.1mm thickness) clockwise on male threads.
Tighten to 1.2-1.5N·m torque using 8mm crowfoot wrench.
Avoid axial misalignment exceeding 3° during assembly.
Compatibility note:
Not recommended for use with ester-based lubricants or acidic media.
Always install downstream of 40μm filter when using unregulated compressed air.
| Property | Property Value |
|---|---|
| sku | APX4-M5 |
