Description
1. Copper-free construction ensures direct applicability in copper-restricted environments;
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
Installation protocol:
Apply thread sealant (PTFE tape or Loctite 577) to male threads only.
Maximum torque: 2.5 N·m (22 in-lb). For gas applications, perform
helium leak test at 0.6 MPa after installation.
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Connector APX4-M8 Technical Details
- Model: APX4-M8 (Y-Type)
- Body material: Nickel-plated brass (Stainless steel variant APX4-M8-SS available)
- Thread standard: Metric fine thread (M8×1.0)
- Port configuration: 3-way equal diameter (1 inlet / 2 outlets)
- Pressure range: 0-1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) standard / Optional FKM (Fluorocarbon)
- Flow coefficient (Cv): 0.45
- Weight: 12.8g ±0.5g
- Dimensions: 24mm (L) × 24mm (W) × 28mm (H)
- Surface hardness: HV300-400 (brass version)
- Anti-vibration design: Thread lock grooves on all ports
- IP rating: IP40 (dust protected)
Precision-engineered Y-shaped pneumatic connector with 120° branch angle for optimized flow distribution. Features triple O-ring seals (2mm cross-section) and anti-rotation flats for wrench tightening. Compatible with ISO 15407-1 standards, rated for 500,000+ duty cycles.
Industrial Applications:
- Modular pneumatic manifolds in assembly robots
- Dual-actuator control systems (e.g., clamping devices)
- Compressed air distribution in semiconductor fab tools
- Mobile hydraulic/pneumatic hybrid circuits
- Vacuum line splitting for pick-and-place units
Installation protocol:
Apply thread sealant (PTFE tape or Loctite 577) to male threads only.
Maximum torque: 2.5 N·m (22 in-lb). For gas applications, perform
helium leak test at 0.6 MPa after installation.
Verified Compatibility:
- Works with 4mm OD polyurethane/nylon tubing (push-to-connect)
- Seamless pairing with AirTAC MXQ8 series quick couplings
- Chemical-resistant version available for CO2 systems
| Property | Property Value |
|---|---|
| sku | APX4-M8 |
