Airtac BPMF Full Metal Internal Thread Bulkhead Straight Fitting BPMF1003
AirTAC BPMF1003 Full Metal Internal Thread Bulkhead Straight Fitting Specifications
- Model: BPMF1003
- Type: 304 Stainless Steel Straight Through Bulkhead Fitting
- Thread Standard: Metric (M10×1.25 internal thread both ends)
- Port Connection: Dual female threads with O-ring seal
- Pressure Rating: 1.5 MPa (217 PSI) maximum working pressure
- Temperature Range: -20℃ to 150℃
- Seal Material: FKM (Fluoroelastomer) for high temp resistance
- Surface Treatment: Passivation for corrosion resistance
- Weight: 28g ±1g (excluding packaging)
- Dimensions: 32mm(Overall Length) × 17mm(Hex Size) × 12mm(Tube OD Pass-through)
- Installation Torque: Recommended 4-5 N·m with thread sealant
- Compliance: RoHS compliant, ISO 9001 certified manufacturing
Heavy-duty bulkhead fitting designed for permanent installations requiring leak-free connections through panels or walls. Features full stainless steel construction with precision-machined threads and a compression-style sealing system. The through-hole design allows continuous tubing passage while maintaining structural integrity in high-vibration environments.
- Pneumatic control cabinet panel mounting
- Hydraulic system bulkhead connections
- Food processing equipment with CIP requirements
- Semiconductor manufacturing gas lines
- Marine hydraulic systems requiring saltwater resistance
Installation note:
Always deburr panel holes before installation. Use thread sealant on male components only.
For maintenance, replace O-rings (AS568-010 standard) every 5 years or 10,000 pressure cycles.
| Property | Property Value |
|---|---|
| sku | BPMF1003 |
