Airtac CM3HD Double Acting Selector Mechanical Valve CM3HD05Y
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with multiple actuator configurations for diverse application requirements.
3. Poppet valve structure ensures superior sealing performance and smooth directional switching without lubrication requirements.
4. Supports versatile mounting orientations for enhanced installation flexibility.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuator heads for extended service life and operational reliability.
6. CM3PMS and CM3PMX series are equipped with protective metal shrouds to prevent accidental actuation and ensure button integrity.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3HD
AirTAC CM3HD Double-Action Selector Mechanical Valve CM3HD05Y Specifications
- Model: CM3HD05Y
- Type: 5-port/3-position double-action selector valve (manual/mechanical actuation)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure range: 0.1–0.8 MPa (14.5–116 PSI)
- Maximum flow rate: 750 L/min (ANR)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Body material: Aluminum alloy with hard anodized finish
- Seal material: NBR (Nitrile) rubber standard (Viton optional)
- Mounting style: Sub-base or direct piping (ISO 15407-1 compliant)
- Weight: 350g ±5% (0.77 lbs)
- Dimensions: 60mm(L) × 40mm(W) × 35mm(H) (2.36" × 1.57" × 1.38")
- Port thread depth: 10mm (0.39")
- Operating force: ≤5N (manual lever actuation)
- Leakage rate: <0.1 mL/min under 0.5 MPa pressure
Robust mechanical selector valve featuring dual-action control with positive position feedback. The CM3HD05Y combines manual override capability with mechanical actuation compatibility, designed for systems requiring fail-safe position selection. Features wear-resistant spool design with self-lubricating guides, optimized for high-cycle applications. Requires 5μm filtered air (ISO 8573-1:2010 Class 3.4.2).
- Production line mode selection systems
- Emergency stop pneumatic circuits
- Multi-station equipment with manual override requirements
- Material handling system diverters
- Test bench pressure path switching
- Packaging machine safety interlocks
Installation note:
Ensure proper port alignment during assembly - arrow markings indicate flow direction.
For mechanical actuation setups, maintain ≤3mm actuator stroke margin.
Lubricate pivot points with ISO VG32 hydraulic oil during maintenance.
| Property | Property Value |
|---|---|
| sku | CM3HD05Y |
| Position | 3-Port 2-Position |
| Port Size | M5 |
