Airtac CM3HD Double Acting Selector Mechanical Valve CM3HD06-P2
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with multiple actuator configurations for diverse application requirements.
3. Poppet valve structure ensures superior sealing performance and smooth directional switching without lubrication requirements.
4. Supports versatile mounting orientations for enhanced installation flexibility.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuator heads for extended service life and operational reliability.
6. CM3PMS and CM3PMX series are equipped with protective metal shrouds to prevent accidental actuation and ensure button integrity.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3HD
AirTAC CM3HD Double-Action Selector Mechanical Valve CM3HD06-P2 Technical Details
- Model Code: CM3HD06-P2
- Valve Type: 3-position double-action selector valve (Center closed)
- Port Configuration: 3 ports (P, A, B) / 2 positions
- Port Thread: PT1/4 (G1/4 optional)
- Operating Pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max Flow Rate: 350 L/min (ANR) at 0.5 MPa
- Actuation Force: ≤5 N (Manual lever operation)
- Body Material: Nickel-plated brass
- Seal Material: NBR + Polyurethane hybrid
- Ambient Temperature: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 220g ±5g
- Dimensions: 50mm(L) × 25mm(W) × 50mm(H)
- Mounting: Panel mount with M4 screw holes
- Response Time: ≤0.3s (Full stroke)
- Leakage: ≤5 bubbles/min (ISO 6952 test)
- Protection Class: IP40 (Dust protected)
Robust mechanical selector valve featuring dual-action positive position locking mechanism. The CM3HD06-P2 utilizes a spring-assisted toggle lever for precise mid-position cutoff control, with hardened stainless steel pivot points ensuring 500,000+ cycle durability. Includes integrated silencer and anti-vibration pads for noise reduction below 65dB(A). Requires 5μm filtered compressed air with oil mist lubrication recommended.
- Production line fixture clamping sequence control
- Plastic injection molding machine safety interlocks
- Textile machinery pneumatic circuit switching
- Automated assembly station tool changers
- Hydraulic system pilot pressure control
Maintenance Protocol:
Lubricate pivot points every 3 months using ISO VG32 turbine oil.
Avoid lateral force exceeding 10N on the operation lever.
For horizontal mounting, install drip shield (accessory CM3-SHIELD01).
