Airtac CM3HD Double Acting Selector Mechanical Valve CM3HD06-P4
$9.73
Regular price
$17.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3HD06-P4
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Description of AirTAC CM3HD Double-acting Selector Mechanical Valve:
1. CM3B, CM3L, CM3V, and CM3R series utilize externally provided actuation force for directional switching, suitable for position detection or limit switch applications.
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with multiple actuator configurations for diverse application requirements.
3. Poppet valve structure ensures superior sealing performance and smooth directional switching without lubrication requirements.
4. Supports versatile mounting orientations for enhanced installation flexibility.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuator heads for extended service life and operational reliability.
6. CM3PMS and CM3PMX series are equipped with protective metal shrouds to prevent accidental actuation and ensure button integrity.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3HD
Installation guidelines:
Apply thread sealant only on male ports (not required for flange connections).
For vertical mounting, orient identification label upward. Lubricate pivot points
with ISO VG32 hydraulic oil during annual maintenance. Maximum allowable side
load on handle: 15N.
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with multiple actuator configurations for diverse application requirements.
3. Poppet valve structure ensures superior sealing performance and smooth directional switching without lubrication requirements.
4. Supports versatile mounting orientations for enhanced installation flexibility.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuator heads for extended service life and operational reliability.
6. CM3PMS and CM3PMX series are equipped with protective metal shrouds to prevent accidental actuation and ensure button integrity.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3HD
AirTAC CM3HD06-P4 Double-Action Selector Mechanical Valve Specifications
- Model: CM3HD06-P4
- Type: 5/3-way double-action selector valve (manual mechanical operation)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Flow capacity: 850 L/min (Cv=1.4)
- Actuation force: ≤3.5 N
- Body material: Anodized aluminum alloy (hard coat treatment)
- Seal material: Heat-resistant NBR (-20℃ to 120℃)
- Weight: 480g ±2%
- Dimensions: 72mm(L) × 48mm(W) × 34mm(H)
- Port thread depth: 12mm (with O-ring groove)
- Operating temperature: -20℃ to 80℃ (with silicone seals optional for 150℃)
- Vibration resistance: 10–55Hz with 1.5mm amplitude
- Shock resistance: 100m/s² (3 axes)
- Mounting: Panel mount with M5 fasteners (IP54) or ISO 15407-1 compliant sub-base
Industrial-grade manual selector valve featuring positive center position detent and tactile feedback. The hardened steel shaft with PTFE bushing ensures smooth operation for >500,000 cycles. Optimized flow paths reduce pressure drop by 18% compared to previous models. Includes dust wiper seals for harsh environments.
Typical Applications:
- Emergency override systems in automated production lines
- Pneumatic circuit configuration switching in CNC machinery
- Manual mode selection for robotic tool changers
- Mobile hydraulic equipment control stations
- Process control override in semiconductor manufacturing
Installation guidelines:
Apply thread sealant only on male ports (not required for flange connections).
For vertical mounting, orient identification label upward. Lubricate pivot points
with ISO VG32 hydraulic oil during annual maintenance. Maximum allowable side
load on handle: 15N.
