Airtac CM3HD Double Acting Selector Mechanical Valve CM3HD06Y
$29.53
Regular price
$37.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3HD06Y
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Description of AirTAC CM3HD Double-acting Selector Mechanical Valve:
1. CM3B, CM3L, CM3V, and CM3R series utilize externally provided actuation force for directional switching, suitable for position detection or limit switch applications.
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with multiple actuator configurations for diverse application requirements.
3. Poppet valve structure ensures superior sealing performance and smooth directional switching without lubrication requirements.
4. Supports versatile mounting orientations for enhanced installation flexibility.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuator heads for extended service life and operational reliability.
6. CM3PMS and CM3PMX series are equipped with protective metal shrouds to prevent accidental actuation and ensure button integrity.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3HD
Installation guidelines:
For vertical installations, ensure exhaust ports face downward. Apply thread sealant only on male threads,
avoiding contamination of pilot channels. Lubricate seals with ISO VG32-grade pneumatic oil during maintenance.
Critical note:
Do not use silicone-based lubricants with HNBR seals. Maximum allowable lateral
force on manual override knob is 15N. Install lockout tags when used in safety circuits.
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with multiple actuator configurations for diverse application requirements.
3. Poppet valve structure ensures superior sealing performance and smooth directional switching without lubrication requirements.
4. Supports versatile mounting orientations for enhanced installation flexibility.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuator heads for extended service life and operational reliability.
6. CM3PMS and CM3PMX series are equipped with protective metal shrouds to prevent accidental actuation and ensure button integrity.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3HD
AirTAC CM3HD Double-Action Selector Mechanical Valve CM3HD06Y Technical Details
- Model: CM3HD06Y
- Type: 5/2-way double pilot operated mechanical valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa
- Max flow rate: 850 L/min (ANR)
- Actuation force: ≤3.5N (manual operation)
- Weight: 320g ±5%
- Dimensions: 58mm(L) × 40mm(W) × 72mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR (hydrogenated nitrile)
- Temperature range: -10℃ to 80℃ (with silicone seals optional for -20℃)
- Response time: ≤50ms (at 0.5MPa)
- Mounting type: Sub-base or direct piping (ISO 15407-1 compliant)
- Protection rating: IP67 (dust/water resistant)
Robust mechanical selector valve featuring dual manual override options (push-pull & rotary knob) for emergency operation. The dual-pilot design ensures stable switching even under pressure fluctuations. Optimized flow path reduces air turbulence by 30% compared to previous models.
Industrial Applications:
- Production line emergency stop systems
- Plastic injection molding machine mode selection
- Textile machinery pneumatic circuit switching
- Automated warehouse conveyor diverters
- Semiconductor equipment maintenance bypass
Installation guidelines:
For vertical installations, ensure exhaust ports face downward. Apply thread sealant only on male threads,
avoiding contamination of pilot channels. Lubricate seals with ISO VG32-grade pneumatic oil during maintenance.
Critical note:
Do not use silicone-based lubricants with HNBR seals. Maximum allowable lateral
force on manual override knob is 15N. Install lockout tags when used in safety circuits.
| Property | Property Value |
|---|---|
| sku | CM3HD06Y |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
