Airtac CM3HD Double Acting Selector Mechanical Valve CM3HD08R
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with multiple actuator configurations for diverse application requirements.
3. Poppet valve structure ensures superior sealing performance and smooth directional switching without lubrication requirements.
4. Supports versatile mounting orientations for enhanced installation flexibility.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuator heads for extended service life and operational reliability.
6. CM3PMS and CM3PMX series are equipped with protective metal shrouds to prevent accidental actuation and ensure button integrity.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3HD
AirTAC CM3HD Double-Action Selector Mechanical Valve CM3HD08R Specifications
- Model: CM3HD08R
- Type: 5-port 3-position double-action selector valve (mechanical lever operation)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 750 L/min (ANR)
- Actuation force: ≤5 N (lever operation)
- Body material: Aluminum alloy (anodized surface)
- Seal material: NBR (nitrile rubber) standard, optional FKM/Viton
- Temperature range: -20℃ to 80℃ (NBR seals), -10℃ to 100℃ (FKM seals)
- Weight: 480g ±5% (including accessories)
- Dimensions: 64mm(L) × 48mm(W) × 82mm(H)
- Port thread depth: 12mm (all ports)
- Response time: ≤50ms (full stroke)
- Mounting options: Panel mount with M4 screws or DIN rail compatible
- Protection rating: IP67 (when properly installed)
Robust mechanical selector valve designed for manual override operations in pneumatic systems. Features zero-power operation with tactile lever feedback, corrosion-resistant construction, and dual exhaust ports for bidirectional control. Includes built-in locking mechanism for position retention. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Production line emergency override systems
- Material handling equipment mode selection
- Test bench pneumatic circuit configuration
- Packaging machine manual adjustment modes
- Automated assembly line maintenance bypass
Installation note:
Lubricate lever pivot points monthly with ISO VG32 pneumatic oil.
Ensure 15° maximum angular deviation from vertical mounting position.
Use thread sealant on port connections (not included).
| Property | Property Value |
|---|---|
| sku | CM3HD08R |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
