Airtac CM3PF Flat Push Button Mechanical Valve CM3PF05R
1. CM3B, CM3L, CM3V, and CM3R series require external force for directional switching, suitable for position detection or limit switch applications.
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with multi-configuration actuator heads for diverse operational conditions.
3. Shut-off type structure ensures excellent sealing performance, responsive direction switching, and lubrication-free operation.
4. Multi-position mounting capability enables flexible installation configurations.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for enhanced durability and operational stability.
6. CM3PMS and CM3PMX series integrate metal protective covers to safeguard button caps and prevent accidental activation from external forces.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PF
AirTAC CM3PF05R Flat-Head Push Button Mechanical Valve Specifications
- Model: CM3PF05R
- Type: 3/2-way manual reset mechanical valve (spring return)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Flow capacity: 450 NL/min (ANR)
- Actuation force: 35N ±5N
- Valve body material: Nickel-plated brass
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -10℃ to 80℃ (14℉ to 176℉)
- Weight: 180g ±5g
- Dimensions: 40mm(L) × 40mm(W) × 25mm(H)
- Mounting type: Direct panel mounting (requires 16mm cutout)
- Electrical connection: Lead wire 22AWG (300mm length)
- Mechanical life: ≥500,000 cycles
Compact manual override valve with tactile feedback, featuring dual-color (red/black) actuator for visual status confirmation. The anti-vibration design maintains stable operation under 5G vibration environments. Integrated dust shield prevents particulate ingress during maintenance operations.
- Emergency stop systems in injection molding machines
- Manual override for automated assembly line jigs
- Pneumatic circuit isolation during equipment maintenance
- Process control in semiconductor wafer handling systems
- Safety interlocks for packaging machinery
Operation guidance: Apply perpendicular force to button surface during activation.
For continuous operation, use pulse mode with ≥1 second interval between actuations.
Lubricate pivot points every 50,000 cycles using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | CM3PF05R |
| Position | 3-Port 2-Position |
| Port Size | M5 |
