Airtac CM3PM Mushroom Push Button Mechanical Valve CM3PM05B
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override operation with diverse ergonomic actuator head designs to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, smooth shifting, and maintenance-free operation without lubrication.
4. Multi-position mounting options enhance installation flexibility and ease of integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate robust metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with protective metal shrouds to safeguard the button head against accidental impacts and prevent unintended actuation, ensuring safe and dependable performance.
Category: Mechanical Valves | Brand: AIRTAC | Series: CM3PM
AirTAC CM3PM05B Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PM05B
- Type: 3/2-way manual reset mechanical valve (spring return)
- Port size: PT1/4 (G1/4 thread standard)
- Operating pressure: 0.1–0.7 MPa
- Actuation force: 50N ±10%
- Body material: Nickel-plated brass
- Seal material: NBR (nitrile rubber)
- Temperature range: -5℃ to 60℃
- Weight: 215g ±5g
- Dimensions: 50mm(L) × 30mm(W) × 72mm(H)
- Button diameter: 40mm (ISO 13850 compliant)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Mounting: Panel mounting with M20×1.5 thread
- Mechanical life: ≥500,000 cycles
Emergency-stop style mushroom head valve with instant manual override capability. Features a lockable red button with yellow base for safety compliance, requiring 2.5mm minimum panel thickness for secure installation. The dual-color design enhances visibility in industrial environments.
- Emergency stop systems in CNC machinery
- Safety circuit initiation in press machines
- Manual override for automated production lines
- Training simulators for industrial equipment
- Process interruption in chemical handling systems
Operation note:
Requires full depression (8mm travel) for reliable actuation.
Monthly functional tests recommended for safety-critical applications.
Compatible with 6mm pneumatic tubing for optimal flow performance.
| Property | Property Value |
|---|---|
| sku | CM3PM05B |
| Position | 3-Port 2-Position |
| Port Size | M5 |
