Airtac CM3PM Mushroom Push Button Mechanical Valve CM3PM05R
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override operation with diverse ergonomic actuator head designs to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, smooth shifting, and maintenance-free operation without lubrication.
4. Multi-position mounting options enhance installation flexibility and ease of integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate robust metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with protective metal shrouds to safeguard the button head against accidental impacts and prevent unintended actuation, ensuring safe and dependable performance.
Category: Mechanical Valves | Brand: AIRTAC | Series: CM3PM
AirTAC CM3PM05R Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PM05R
- Type: 3/2-way manual mechanical valve (spring return)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.2–0.8 MPa
- Body material: Brass with nickel plating
- Button material: PBT plastic (anti-UV treated)
- Seal material: NBR (nitrile rubber)
- Operating temperature: -5℃ to 80℃
- Actuation force: 3.5–4.5N
- Mounting type: Panel mount (10mm thickness max)
- Weight: 85g ±2g
- Dimensions: 30mm(W) × 30mm(D) × 42mm(H)
- Protection rating: IP65 (front face), IP40 (rear)
- Mechanical life: ≥500,000 cycles
Emergency-stop style manual valve featuring a 32mm diameter mushroom head with lockable twist release mechanism. The bright red button provides instant airflow cutoff with positive tactile feedback. Reinforced stem design prevents accidental activation, while the corrosion-resistant construction withstands oil mist and particulate exposure.
- Emergency stop systems in packaging machinery
- Manual override in automated production lines
- Safety interlocks for press equipment
- Pneumatic system maintenance bypass
- Mobile hydraulic platform controls
Installation note:
Requires 25mm minimum panel depth for proper mounting.
Apply thread sealant on port connections and perform monthly
button rotation checks to prevent sticking. Compatible with
ISO 13850 safety standards when used with appropriate relays.
| Property | Property Value |
|---|---|
| sku | CM3PM05R |
| Position | 3-Port 2-Position |
| Port Size | M5 |
