Airtac CM3PM Mushroom Push Button Mechanical Valve CM3PM05Y
$21.16
Regular price
$28.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3PM05Y
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
CM3PM Mushroom Head Push Button Mechanical Valve (Series: CM3PM, Brand: AIRTAC)
1. The CM3B, CM3L, CM3V, and CM3R series require externally provided shifting force for actuation, making them ideal for position sensing or limit switch applications.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override operation with diverse ergonomic actuator head designs to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, smooth shifting, and maintenance-free operation without lubrication.
4. Multi-position mounting options enhance installation flexibility and ease of integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate robust metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with protective metal shrouds to safeguard the button head against accidental impacts and prevent unintended actuation, ensuring safe and dependable performance.
Category: Mechanical Valves | Brand: AIRTAC | Series: CM3PM
Installation guidelines:
Mount within 600mm horizontal reach of operators (EN ISO 13857 compliance).
Ensure full button travel (8mm stroke) without obstruction.
Use thread sealant on port connections - do not overtighten (max 15N·m torque).
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override operation with diverse ergonomic actuator head designs to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, smooth shifting, and maintenance-free operation without lubrication.
4. Multi-position mounting options enhance installation flexibility and ease of integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate robust metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with protective metal shrouds to safeguard the button head against accidental impacts and prevent unintended actuation, ensuring safe and dependable performance.
Category: Mechanical Valves | Brand: AIRTAC | Series: CM3PM
AirTAC CM3PM05Y Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PM05Y
- Type: 3/2-way normally closed (manual reset)
- Operation style: Lockable mushroom head with twist-to-release mechanism
- Port size: G1/8 (ISO228 standard) with NPT1/8 optional
- Operating pressure range: 0.05–0.8 MPa
- Max flow rate: 750 L/min (ANR)
- Button diameter: 40mm (ISO 13850 compliant emergency stop size)
- Actuation force: 50-60N (meet CE safety requirements)
- Body material: Anodized aluminum alloy with stainless steel spring
- Seal material: High-grade NBR (nitrile) rubber
- Temperature range: -10℃ to 80℃ (with anti-freeze lubrication)
- Protection rating: IP67 (dust/water resistant)
- Mounting style: Panel mounting with M25 mounting thread
- Electrical contacts: 2NO + 2NC (silver alloy contacts, 5A 250VAC)
- Mechanical life: ≥500,000 cycles
- Weight: 280g ±5% (including mounting hardware)
- Dimensions: 58mm(H) × 48mm(D) × 48mm(W) (head protrusion: 15mm)
Industrial-grade emergency stop valve with positive break safety design, featuring a highly visible red mushroom head with yellow base ring. The dual-circuit contact block enables simultaneous control of pneumatic systems and electrical safety circuits. Requires manual rotation (45°) for reset after activation. Built-in mechanical latching prevents accidental release.
Typical Applications:
- Emergency stop systems for CNC machinery
- Safety interlocks in automated production lines
- Robotic cell safety stations
- Press machine two-hand control systems
- Packaging equipment safety gates
Installation guidelines:
Mount within 600mm horizontal reach of operators (EN ISO 13857 compliance).
Ensure full button travel (8mm stroke) without obstruction.
Use thread sealant on port connections - do not overtighten (max 15N·m torque).
Compliance: Meets ISO 13850 (emergency stop) and IEC 60947-5-5 (safety switches) standards.
Requires monthly functional testing in safety-critical applications.
| Property | Property Value |
|---|---|
| sku | CM3PM05Y |
| Position | 3-Port 2-Position |
| Port Size | M5 |
