Airtac CM3PM Mushroom Push Button Mechanical Valve CM3PM06-P2
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override operation with diverse ergonomic actuator head designs to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, smooth shifting, and maintenance-free operation without lubrication.
4. Multi-position mounting options enhance installation flexibility and ease of integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate robust metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with protective metal shrouds to safeguard the button head against accidental impacts and prevent unintended actuation, ensuring safe and dependable performance.
Category: Mechanical Valves | Brand: AIRTAC | Series: CM3PM
AirTAC CM3PM Mushroom Head Push Button Mechanical Valve CM3PM06-P2 Specifications
- Model: CM3PM06-P2
- Type: 3/2-way normally closed (manual reset)
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: ISO 228 (BSPP)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 1,200 NL/min
- Actuation force: 50N ±10%
- Reset type: Twist-to-release mechanism
- Body material: Anodized aluminum alloy
- Seal material: High-grade NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 280g ±5% (including mounting hardware)
- Dimensions: 54mm(D) × 54mm(H) × 86mm(W)
- Mounting style: Panel mount with M18 locknut
- Protection rating: IP67 (dust/water resistant)
- Mechanical life: ≥500,000 cycles
Emergency stop valve with ergonomic mushroom head design (Ø40mm yellow actuator) meeting ISO 13850 safety standards. Features positive mechanical latching with visual position indicator window. The zinc-plated steel spring ensures reliable reset operation even in high-vibration environments. Requires manual twist-release (45° rotation) after activation.
- Emergency shutdown systems in CNC machinery
- Safety interlocks for automated production lines
- Press brake and power press emergency stops
- Robotic cell safety circuits
- Packaging equipment safety gates
- Elevator emergency control panels
Installation guidelines:
Mount with 1.5-2Nm torque using included M18 nut. Ensure 360° accessibility
for emergency operation. Test monthly by full depression (≥8mm travel distance).
Lubricate pivot points with silicone grease every 6 months.
| Property | Property Value |
|---|---|
| sku | CM3PM06-P2 |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
