Airtac CM3PM Mushroom Push Button Mechanical Valve CM3PM06Y
$21.16
Regular price
$28.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3PM06Y
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
CM3PM Mushroom Head Push Button Mechanical Valve (Series: CM3PM, Brand: AIRTAC)
1. The CM3B, CM3L, CM3V, and CM3R series require externally provided shifting force for actuation, making them ideal for position sensing or limit switch applications.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override operation with diverse ergonomic actuator head designs to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, smooth shifting, and maintenance-free operation without lubrication.
4. Multi-position mounting options enhance installation flexibility and ease of integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate robust metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with protective metal shrouds to safeguard the button head against accidental impacts and prevent unintended actuation, ensuring safe and dependable performance.
Category: Mechanical Valves | Brand: AIRTAC | Series: CM3PM
Installation guidelines:
Mount on flat surfaces with minimum 50mm clearance around button.
Use anti-rotation pins for panel mounting. Test monthly by full depression
and verify contact resistance <0.1Ω. Replace if reset force exceeds 15N.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override operation with diverse ergonomic actuator head designs to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, smooth shifting, and maintenance-free operation without lubrication.
4. Multi-position mounting options enhance installation flexibility and ease of integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate robust metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with protective metal shrouds to safeguard the button head against accidental impacts and prevent unintended actuation, ensuring safe and dependable performance.
Category: Mechanical Valves | Brand: AIRTAC | Series: CM3PM
AirTAC CM3PM06Y Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PM06Y
- Type: Push-lock emergency stop valve (3/2-way normally closed)
- Actuation: Mechanical latching with twist-to-reset mechanism
- Port size: M5 (PT1/8 adapter available)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Flow capacity: 200 NL/min (ANR)
- Button diameter: 40mm (ISO 13850 compliant emergency stop size)
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Contact rating: 5A 250VAC (gold-plated contacts)
- Mechanical life: ≥500,000 cycles
- Protection rating: IP65 (front side)/IP40 (rear side)
- Weight: 215g ±5g (including mounting hardware)
- Dimensions: 50mm(L) × 48mm(W) × 82mm(H)
- Mounting: 30mm diameter panel cutout
- Safety compliance: EN 60947-5-5, EN 60204-1
Industrial-grade emergency stop valve featuring a bright red mushroom head with high-visibility yellow base ring. The twist-release mechanism requires deliberate manual reset action after activation, preventing accidental restart. Dual-contact design ensures positive circuit breaking with 0.5mm contact gap safety margin.
Typical Applications:
- Machine tool emergency stop systems
- Robotic cell safety interlocks
- Conveyor system emergency cutoff
- Injection molding machine safety circuits
- Packaging equipment safety stations
Installation guidelines:
Mount on flat surfaces with minimum 50mm clearance around button.
Use anti-rotation pins for panel mounting. Test monthly by full depression
and verify contact resistance <0.1Ω. Replace if reset force exceeds 15N.
Safety Features:
- Positive opening mechanism (NC contacts)
- Tamper-resistant reset collar
- Dual-circuit break configuration
- UV-resistant polycarbonate button
| Property | Property Value |
|---|---|
| sku | CM3PM06Y |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
