Airtac CM3PM Mushroom Push Button Mechanical Valve CM3PM08Y
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override operation with diverse ergonomic actuator head designs to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, smooth shifting, and maintenance-free operation without lubrication.
4. Multi-position mounting options enhance installation flexibility and ease of integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate robust metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with protective metal shrouds to safeguard the button head against accidental impacts and prevent unintended actuation, ensuring safe and dependable performance.
Category: Mechanical Valves | Brand: AIRTAC | Series: CM3PM
AirTAC CM3PM08Y Mushroom Head Push Button Type Mechanical Valve Specifications
- Model: CM3PM08Y
- Type: 3/2-way mechanical valve (spring return)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.05–0.8 MPa
- Button type: Mushroom head (emergency stop style)
- Reset mechanism: Manual twist release
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR
- Operating force: 3.5±0.5 kgf
- Temperature range: -10℃ to 80℃
- Protection rating: IP67 (dust/water resistant)
- Weight: 112g ±2g
- Dimensions: 48mm(L) × 48mm(W) × 38mm(H)
- Mounting: Panel mount (10mm thickness max)
- Contact rating: 5A 250VAC (gold-plated contacts)
Emergency safety valve with positive mechanical engagement, featuring a lockable mushroom head for fail-safe operation. The bright red button with yellow base complies with ISO 13850 emergency stop standards. Enhanced ingress protection allows use in washdown environments. Requires 0.5-1.2Nm torque for panel installation.
- Emergency stop circuits in CNC machinery
- Safety interlocks for automated production lines
- Manual override systems in hydraulic presses
- Material handling equipment emergency controls
- Packaging line safety stations
Installation note:
Ensure full button travel clearance (minimum 8mm depression depth).
Apply thread sealant on port connections - do not overtighten (max 15N·m).
Test twist-release function monthly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | CM3PM08Y |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
