Airtac CM3PMS Mushroom Head Push Button Mechanical Valve CM3PMS05R
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override with multi-configuration actuators for diverse operational conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and maintenance-free operation without lubrication;
4. Multi-directional mounting options enhance installation flexibility;
5. CM3L, CM3V, CM3R, and CM3Y series adopt metallic actuators for extended service life and superior reliability;
6. CM3PMS and CM3PMX series incorporate an integrated protective metal shroud to shield the button cap, preventing accidental actuation and ensuring operational safety.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PMS
AirTAC CM3PMS Mushroom Head Push Button Mechanical Valve CM3PMS05R Specifications
- Model: CM3PMS05R
- Type: 3/2-way normally closed mechanical valve (manual reset)
- Actuation: Mushroom head emergency stop design
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.7 MPa
- Max flow rate: 350 NL/min
- Body material: Anodized aluminum alloy
- Seal material: High-grade NBR (nitrile rubber)
- Button diameter: 40mm (ISO 13850 compliant)
- Operating force: 50N ±10%
- Temperature range: -5℃ to 60℃
- Protection rating: IP67 (dust/water resistant)
- Weight: 215g ±5g
- Dimensions: 48mm(L) × 48mm(W) × 56mm(H)
- Mounting: M5 threaded holes (4-point mounting)
- Mechanical life: ≥100,000 cycles
Emergency safety valve with oversized yellow mushroom head for instant system shutdown. Features twist-to-reset mechanism with positive tactile feedback. The zinc-plated steel spring ensures reliable return even in high-vibration environments. Compatible with ISO 1219-2 pneumatic standards.
- Production line emergency stop stations
- Packaging machinery safety interlocks
- Semiconductor fab equipment controls
- Hydraulic press emergency release systems
- Food processing equipment (FDA-compliant seals)
- Explosion-proof environments (non-electrical actuation)
Installation note:
Mount within 45° of vertical plane for optimal actuation.
Requires monthly functional testing - pull button with 60N force
to verify full travel distance (8mm ±1mm). Lubricate pivot points
with silicone grease every 6 months.
| Property | Property Value |
|---|---|
| sku | CM3PMS05R |
| Position | 3-Port 2-Position |
| Port Size | M5 |
