Airtac CM3PMS Mushroom Head Push Button Mechanical Valve CM3PMS06-P2
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override with multi-configuration actuators for diverse operational conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and maintenance-free operation without lubrication;
4. Multi-directional mounting options enhance installation flexibility;
5. CM3L, CM3V, CM3R, and CM3Y series adopt metallic actuators for extended service life and superior reliability;
6. CM3PMS and CM3PMX series incorporate an integrated protective metal shroud to shield the button cap, preventing accidental actuation and ensuring operational safety.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PMS
AirTAC CM3PMS06-P2 Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PMS06-P2
- Type: 3/2-way normally closed (manual reset)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa
- Actuation force: 30-50N (ergonomic design)
- Body material: Stainless steel SS304
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Thread depth: 12mm (with anti-loosening structure)
- Protection rating: IP65 (dust/water resistant)
- Weight: 220g ±5g
- Dimensions: 48mm(L) × 48mm(W) × 72mm(H)
- Button diameter: 30mm (yellow safety cap)
- Reset type: Manual twist-release mechanism
Emergency stop valve with positive mechanical lock and high-visibility actuator. Features dual-stage sealing for leak-free operation and stainless steel spring for corrosion resistance. The oversized mushroom head allows quick palm activation even with gloves. Requires 0.5-1.5mm² wire for electrical connection.
- Machine tool emergency stop systems
- Assembly line safety interlocks
- Packaging machinery emergency cutoff
- Robotic cell safety stations
- Hydraulic press safety controls
Installation requirements:
Mount within 45° of vertical plane. Maintain minimum 50mm clearance
around button for emergency access. Perform monthly mechanical reset
tests to prevent sticking.
| Property | Property Value |
|---|---|
| sku | CM3PMS06-P2 |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
