Airtac CM3PMS Mushroom Head Push Button Mechanical Valve CM3PMS06-P3
$21.62
Regular price
$29.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3PMS06-P3
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
CM3PMS Mushroom Head Push Button Mechanical Valve (AirTAC)
1. CM3B, CM3L, CM3V, and CM3R series utilize externally provided actuation force for directional switching, ideal for position detection or limit switch applications;
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override with multi-configuration actuators for diverse operational conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and maintenance-free operation without lubrication;
4. Multi-directional mounting options enhance installation flexibility;
5. CM3L, CM3V, CM3R, and CM3Y series adopt metallic actuators for extended service life and superior reliability;
6. CM3PMS and CM3PMX series incorporate an integrated protective metal shroud to shield the button cap, preventing accidental actuation and ensuring operational safety.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PMS
Installation guidelines:
Requires 2.5-5mm thick panel mounting. Use backup wrench on hex base (17mm) during
installation to prevent rotation. Test monthly by full depression and twist verification.
Safety notice:
Must be installed in series with control circuit. Never bypass or modify
the twist-release mechanism. Replace immediately if button shows <3mm travel.
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override with multi-configuration actuators for diverse operational conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and maintenance-free operation without lubrication;
4. Multi-directional mounting options enhance installation flexibility;
5. CM3L, CM3V, CM3R, and CM3Y series adopt metallic actuators for extended service life and superior reliability;
6. CM3PMS and CM3PMX series incorporate an integrated protective metal shroud to shield the button cap, preventing accidental actuation and ensuring operational safety.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PMS
AirTAC CM3PMS06-P3 Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PMS06-P3
- Type: 3/2-way manual mechanical valve (spring return)
- Operation style: Mushroom head emergency stop design
- Port size: G1/8 (ISO228 standard)
- Thread type: External thread (M10×1.0)
- Operating pressure: 0.1–0.8 MPa
- Proof pressure: 1.2 MPa
- Flow capacity: 450 NL/min (at 0.5 MPa)
- Actuation force: 30-50N (ergonomic design)
- Body material: Anodized aluminum alloy (black finish)
- Seal material: Heat-resistant NBR (-20℃ to 100℃)
- Operating temperature: -20℃ to 70℃ (with lubrication)
- Weight: 198g ±5g
- Dimensions: 48mm(D) × 48mm(W) × 68mm(H)
- Mounting: Panel cutout Ø22mm (+0.5/-0mm tolerance)
- Protection rating: IP67 (dust/water resistant)
- Safety compliance: ISO13850 (emergency stop category)
Emergency-stop mechanical valve with oversized 38mm mushroom head for instant system shutdown. Features positive-lock mechanism requiring twist-release to reset, preventing accidental reactivation. Integrated O-ring seal ensures leak-free performance in vertical/horizontal installations.
Industrial Applications:
- Production line emergency stop stations
- Robotic cell safety interlocks
- Hydraulic press safety circuits
- Packaging machinery safety gates
- CNC machine tool emergency stops
- Training simulator kill switches
Installation guidelines:
Requires 2.5-5mm thick panel mounting. Use backup wrench on hex base (17mm) during
installation to prevent rotation. Test monthly by full depression and twist verification.
Safety notice:
Must be installed in series with control circuit. Never bypass or modify
the twist-release mechanism. Replace immediately if button shows <3mm travel.
| Property | Property Value |
|---|---|
| sku | CM3PMS06-P3 |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
