Airtac CM3PMS Mushroom Head Push Button Mechanical Valve CM3PMS06Y
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override with multi-configuration actuators for diverse operational conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and maintenance-free operation without lubrication;
4. Multi-directional mounting options enhance installation flexibility;
5. CM3L, CM3V, CM3R, and CM3Y series adopt metallic actuators for extended service life and superior reliability;
6. CM3PMS and CM3PMX series incorporate an integrated protective metal shroud to shield the button cap, preventing accidental actuation and ensuring operational safety.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PMS
AirTAC CM3PMS06Y Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PMS06Y
- Type: 3/2-way normally closed mechanical valve (manual override)
- Actuation type: Mushroom head emergency stop design
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.2–1.0 MPa
- Max flow rate: 850 L/min
- Body material: Nickel-plated brass
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -10℃ to 80℃ (with intermittent peaks to 120℃)
- Mechanical life: ≥500,000 cycles
- Weight: 320g ±5g
- Dimensions: 58mm(L) × 58mm(W) × 45mm(H)
- Mounting: Panel mount with M22×1.5 thread
- Protection rating: IP67 (dust/water resistant)
- Safety compliance: ISO 13850 (emergency stop function)
Robust emergency stop valve with oversized 38mm mushroom head for quick palm activation. Features twist-to-reset mechanism with positive tactile feedback and dual-color position indicator (red/yellow). The through-port design minimizes pressure drop, optimized for high-flow emergency air release in safety circuits.
- Press machine emergency stop systems
- Assembly line safety interlocks
- Robotic cell emergency air dump
- Packaging machinery safety stations
- Plastic injection molding machine guards
Installation note:
Requires 50N activation force (EN ISO 13850 compliant). Mount within 600mm horizontal reach of operator position. Perform monthly functional tests with full-stroke activation to prevent seal memory. Compatible with 40μm filtration systems.
| Property | Property Value |
|---|---|
| sku | CM3PMS06Y |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
